Hydraulic check valve threaded cartridge valve TJ025-5/5115

Design factor

The importance of universal design of cartridge valve and its valve hole lies in mass production. Take a cartridge valve of a certain specification as an example. For mass production, the size of its valve port is uniform. In addition, valves with different functions can use the same valve cavity, such as one-way valve, cone valve, flow regulating valve, throttle valve, two-position solenoid valve and so on. If valves with the same specification and different functions can't use different valve bodies, the processing cost of valve blocks will inevitably increase, and the advantages of cartridge valves will no longer exist.

Cartridge valves are widely used in the field of fluid control function. The applied components are electromagnetic directional valve, one-way valve, overflow valve, pressure reducing valve, flow control valve and sequence valve. The extension of universality in fluid power circuit design and mechanical practicability fully demonstrates the importance of cartridge valve to system designers and users. Because of the universality of its assembly process, the universality and interchangeability of valve hole specifications, the use of cartridge valves can completely realize perfect design and configuration, and also make cartridge valves widely used in various hydraulic machinery.

Small size and low cost

The benefits of mass production to users have already appeared before the valve block has reached the end of the assembly line. The whole set of control system designed by cartridge valve can greatly reduce manufacturing man-hours for users; Each component of the control system can be independently tested before being assembled into an integrated valve block; The integrated block can be tested as a whole before it is sent to users.

Because the number of components that must be installed and connected pipelines is greatly reduced, a lot of manufacturing man-hours are saved for users. Due to the reduction of system pollutants, leakage points and assembly errors, the reliability is significantly improved. The application of cartridge valve realizes the high efficiency and convenience of the system.
